V-Blocks

V-Blocks
V-Blocks
Product Code : VB 16
Brand Name : microflat
Product Description

With excellent team of experts, we are successfully manufacturing and exporting a superior quality range of V-Blocks. It is designed by utilizing premium quality component in conformity with predefined industry standards at our well equipped production unit. Our entire range is used in workshops, tool rooms & construction sections for variety of application such as marking accurate centers, checking concentricity and parallelism. The offered V-Blocks can be easily availed from us in multiple power ratings at an affordable price.

Features:

  • Excellent design
  • Easy installation
  • Rust proof coating
Specifications:

Cast Iron Plain V-Blocks               Hardened and Ground Steel V-Blocks
Cast Iron Elongated V-Blocks        Granite V-Blocks
Cast Iron universal V-Blocks          Magnetic V-Blocks

SALIENT FEATURES:

  • Cast Iron Universal V-Blocks, Cast Iron Plain V-Blocks and Cast Iron Elongated V-Blocks are made from close grained Cast Iron Castings conforming to Grade FG-220 of IS-210, offered duly hand-scrapped finish.
  • Universal V-Blocks & Elongated V-Blocks are generally conforming to IS-4960-1968 and Plain V-blocks are generally conforming to IS-2949-1992.
  • Steel V-Blocks are made from hardened & ground alloy steel having hardness 55 - 60 HRC generally  conforming to IS 2949- 1992 available in different Grades of accuracies. i.e. Grade-0, Grade-1 and Grade-2 accuracy limits, having included Angle 90± 5'.
  • Granite V-Blocks made from good quality Granite, working  faces offered duly finely lapped finish having included Angle 90± 5'.
  • Magnetic V-Block has a total 3 Magnetic surfaces. Top and bottom with 90 V-Angle and end surface opposite to  switch. Magnetic V-Blocks are offered in two types i.e. soft and hardened.
  • Clamps offered for Plain V-Blocks (Cast Iron and hardened and ground steel and Granite V-Blocks) on request.
